5 Lac - 6.50 Lac / piece
| Business Type | Manufacturer, Supplier, Retailer, Trader |
| Laser Power | 1000w/1500w/2000w |
| Laser Type | Fiber |
| Laser Wavelength | 1070 NM |
| Click to view more | |
Product Details
Welding Head
Qilin / Getfasst
Water Chiller Power Rating
1.8 KW
Power Required
220VA20% /AC /50HZ
Power Consumption
5 KW / 7KW
Fiber Optical Cable Length
10 M
Fiber Core Diameter
50 Micron
Cooling Way
Water Cooling
Warranty
Laser Head - 1 Year, Laser Source - 2
control System
Gefasst / Qilin
cooling System
Hanli
Features
\\n- \\n
- Equipped with self-invented wobble welding head, we developed the wobble welding mode. \\n
- Our products remedy the inadequacies of the traditional loser product switch the alternating spot size and the high fault tolerance, obtaining a better formation of weld. \\n
- Different welding manners with various welding heads con be realized through the simple operation \\n
.
| DETAILS OF LASER WELDING HEAD | |
| Brand | GEFASST / QILIN |
| Max laser power | 1000 W / 1500 W / 2000W / 3000 W |
| Spot size | Width 5mm |
.
| MACHINE DETAILS | |
| Dimension | 1100*555* 1095 mm |
| Net Weight | 145/150/160 Kgs |
| Gross weight | 210 Kgs/td> |
| Package size | 1150 *700*1200 mm |
| Package Type | Export Fumigation- free Wooden Box |
.
| WELDING CAPACITY | |||||
| MODEL | Carbon Steel | Aluminum Alloy | Stainless Steel | Galvanized Sheet | |
| 1000W | <2mm | <1mm | <2mm | <1mm | |
| 1500W | 4mm | 1mm | 4mm | <1mm | |
| 2000W | 6mm | <3mm | 6mm | <3mm | |
| 3000W | 8mm | 4mm | 8mm | 4mm | |
