MIG/MAG?MMA Welding Machines

Leading Manufacturers, Exporters, Wholesaler, Retailer and Trader of Mag/ARC 200 Welding Machine, Mag/ARC 250 Welding Machine, MIG 250 Welding Machine, MIG/ARC 400 Welding Machine and MIG/ARC 600 Welding Machine from Chennai.

Mag/ARC 200 Welding Machine

Business Type	Manufacturer, Supplier, Retailer, Trader
Efficiency (%)	85
Input Power Voltage	AC 240V (1 phase) ±10% 50/60
Rated Input Power Capacity(KVA)	6.4
Output Current Ranges(A)	50 -200
Rated Output Voltage(V)	26
Duty Cycle(%)	60
Weight(KGs)	25

Power Factor	0.93
Over all dimension (mm)	500263430
Post Gas (sec)	1±0.5
Wire Speed m/min	2.0-10
Welding Coil Dia (mm)	0.8
Power factor	0.93
Protection Class of Case	Ip21
Diameter of Arc welding electrode (mm)	1.6 - 3.15

Click to view more

Features

Power Saving up to 30 - 70 %
Power Factor (PF) more than 0.9
Good ARC start and arc force
Suitable to weld all kind of Electrodes
Less spatter and good welding bead
ARC strength can be adjusted due to reactor control technology
Small, light, portable and cost effective
Hight duty cycle enables contunies welding.
Three protection (anti-dust, anti damp proof, antisepsis) user friendly design

Request to Call

Mag/ARC 250 Welding Machine

25,000.00 / Piece

Business Type	Manufacturer, Supplier, Retailer, Trader
Efficiency (%)	85
Input Power Voltage	AC 440V (3 phase) ±15% 50/60
Rated Input Power Capacity(KVA)	8.3
Output Current Ranges(A)	50 -250
Rated Output Voltage(V)	26.5
Duty Cycle(%)	60
Weight(KGs)	17.5

Power factor	0.93
Over all dimension (mm)	505218355
Post Gas (sec)	1±0.5
Wire Speed m/min	2.5-13
Welding Coil Dia (mm)	0.8
Protection class of case	IP21
Diameter of Arc welding electrode (mm)	1.6 - 4

Click to view more

Features

Power Saving up to 30 - 70 %
Power Factor (PF) more than 0.9
Good ARC start and arc force
Suitable to weld all kind of Electrodes
Less spatter and good welding bead
ARC strength can be adjusted due to reactor control technology
Small, light, portable and cost effective
Hight duty cycle enables contunies welding.
Three protection (anti-dust, anti damp proof, antisepsis) user friendly design

Request to Call

MIG 250 Welding Machine

22,500.00 - 25,000.00 / piece

Business Type	Manufacturer, Supplier, Retailer, Trader
Input Power Voltage	AC 440V (3 phase) ±15% 50/60
Rated Input Power Capacity(KVA)	9.2
Output Current Ranges(A)	50 -250
Rated Output Voltage(V)	29
Duty Cycle(%)	80
Weight(KGs)	26
Over all dimension (mm)	510275440

Post Gas (sec)	1±0.5
Wire Speed M/min	2.0-10
Welding Coil Dia (mm)	0.8
Efficiency (%)	85
Power factor	0.93
Protection class of case	IP21

Click to view more

Features

Power Saving up to 30 - 70 %
Power Factor (PF) more than 0.9
Good ARC start and arc force
Suitable to weld all kind of Electrodes
Less spatter and good welding bead
ARC strength can be adjusted due to reactor control technology
Small, light, portable and cost effective
Hight duty cycle enables contunies welding.
Three protection (anti-dust, anti damp proof, antisepsis) user friendly design

Request to Call

MIG/ARC 400 Welding Machine

25,000.00 / Piece

Business Type	Manufacturer, Supplier, Retailer, Trader
Input Power Voltage	AC 440V (3 phase) ±15% 50/60
Rated Input Power Capacity(KVA)	13.7
Output Current Ranges(A)	50 -400
Rated Output Voltage(V)	31.5
No Load Voltage(V)	58
Duty Cycle(%)	60
Weight(KGs)	0.93

Over all dimension (mm)	590300620
Post Gas (sec)	1±0.5
Wire Speed m/min	2.5-13
Welding Coil Dia (mm)	0.8-1.2
Efficiency (%)	85
Power factor	0.93
Protection Class of Case	IP21
Diameter of Arc welding electrode (mm)	1.6 - 5

Click to view more

Features

Power Saving up to 30 - 70 %
Power Factor (PF) more than 0.9
Good ARC start and arc force
Suitable to weld all kind of Electrodes
Less spatter and good welding bead
ARC strength can be adjusted due to reactor control technology
Small, light, portable and cost effective
Hight duty cycle enables contunies welding.
Three protection (anti-dust, anti damp proof, antisepsis) user friendly design

Request to Call

MIG/ARC 600 Welding Machine

Business Type	Manufacturer, Supplier, Retailer, Trader
Efficiency (%)	85
Input Power Voltage	AC 440V (3 phase) ±15% 50/60
Rated Input Power Capacity(KVA)	24.4
Output Current Ranges(A)	50 -600
Rated Output Voltage(V)	39
No Load Voltage(V)	70
Duty Cycle(%)	60

Weight(KGs)	50
Power factor	0.95
Over all dimension (mm)	650330620
Post Gas (sec)	1±0.5
Wire Speed m/min	2.5-16
Welding Coil Dia (mm)	0.8-2.6
Protection class of case	IP21
Diameter of Arc Welding Electrode (mm)	1.6 - 6

Click to view more

Features

Power Saving up to 30 - 70 %
Power Factor (PF) more than 0.9
Good ARC start and arc force
Suitable to weld all kind of Electrodes
Less spatter and good welding bead
ARC strength can be adjusted due to reactor control technology
Small, light, portable and cost effective
Hight duty cycle enables contunies welding.
Three protection (anti-dust, anti damp proof, antisepsis) user friendly design

Request to Call
