Sai Welding Machines
Leading Manufacturers, Exporters, Wholesaler, Retailer and Trader of Spot Cum Projection Welding Machine, MMA Welding Machine, MMA/ Tig Welding Machine, AC/DC Pulse Tig Welding Machine, MIG/MAG?MMA Welding Machines, MIG/MAG DIODE & THYRISTOR Welding Machines, Plasma Cutting Machine, SAW Welding Machine and Stud Welding Machine from Chennai.
| Business Type | Manufacturer, Supplier, Retailer, Trader |
| Brand Name | Sai |
| Material | Metal |
| Color | Orange |
| Packaging Type | Standard Packaging |
| Usage | Industrial |
| Power Source | Electric |
| Voltage | 220V |
| Frequency | 50-60Hz |
| Specialities | Spot Welding And Projection Welding Capabilities |
| Dimensions | Standard Dimensions |
| Weight | Varies Based On Model |
| Business Type | Manufacturer, Supplier, Retailer, Trader |
| Input Power Voltage | AC 240V (1 phase) ±10% |
| Rated Input Power Capacity(KVA) | 7 |
| Input Power Freuency(Hz) | 50/60 |
| No Load Voltage(V) | 62 |
| Output Current Ranges(A) | 20 -200 |
| Rated Output Voltage(V) | 27 |
| Duty Cycle(%) | 60 |
| Efficiency (%) | 85 |
| Power factor | 0.93 |
| Weight(KGs) | 8 |
| Overall Dimension (mm) | 440 x218 x355 |
| Protection class of case | IP23 |
| Driver Adjustment Range | 0.60 |
| Diameter of Electrode (mm) | 1.6 -3.15 |
Features
\\n- \\n
- Power Saving up to 30 - 70 % \\n
- Power Factor (PF) more than 0.9 \\n
- Light in weight & compact in size \\n
- High Quality & Spatter less in welding \\n
- Good ARC start and arc force \\n
- Protection against low voltage, high voltage, single phase & surge voltage \\n
- Suitable to weld all kind of Electronics \\n
| Business Type | Manufacturer, Supplier, Retailer, Trader |
| Input Power Voltage | AC 240V (1 phase) ±10% 50/60 |
| Rated Input Power Capacity(KVA) | 3.2 |
| Output Current Ranges(A) | 10 -160 |
| Rated Output Voltage(V) | 16.4 |
| No Load Voltage(V) | 43 |
| Duty Cycle(%) | 60 |
| Weight(KGs) | 8 |
| Overall Dimensions (mm) | 371 x 155 x 295 |
| Post Gas (Sec) | 2.5 |
| Current Of MMA(A) | 20 -160 |
| Welding plate thickness (mm) | 1 -4 |
| Efficiency (%) | 85 |
| Power Factor | 0.93 |
| Protection class of case | IP23 |
Features
\\n- \\n
- Power Saving up to 30 - 70% \\n
- Power Factor (PF) more than 0.9 \\n
- Light in weight & compact in size \\n
- High Quality & Spatter less in welding \\n
- Good ARC start and arc force \\n
- Protection against low voltage, high voltage, single phase & surge voltage \\n
- Suitable to weld all kind of Electrodes \\n
- H.F. Arc Starting with pulse control \\n
- Two functionof DC TIG / MMA \\n
- Be able to weld Mild Steel, Stainless Steel, Copper & Titanium Metals etc. \\n
| Business Type | Manufacturer, Supplier, Retailer, Trader |
| Input Power Voltage | AC 240V (1 phase) ±10% 50/60 |
| Rated Input Power Capacity(KVA) | 4.5 |
| Output Current Ranges(A) | 10 -200 |
| Rated Output Voltage(V) | 18 |
| No Load Voltage(V) | 62 |
| Duty Cycle(%) | 60 |
| Weight(KGs) | 26.6 |
| Overall Dimension (mm) | 493 x330 x320 |
| Post Gas (Sec) | 0 -10 |
| Welding plate thickness (mm) | 0.5 -4 |
| Efficiency (%) | 85 |
| Power factor | 0.93 |
| Protection class of case | IP21S |
Features
- Power Saving up to 30 - 70 %
- Power Factor (PF) more than 0.9
- Light in weight & compact in size
- High Quality & Spatter less in welding
- Good ARC start and arc force
- Protection against low voltage, high voltage, single phase & surge voltage
- Suitable to weld all kind of Electronics
- H.F. Arc Starting with pulse control
- Two functionof DC TIG / MMA
- Be able to weld Mild Steel, Stainless Steel, Copper & Titanium Metals etc.
| Business Type | Manufacturer, Supplier, Retailer, Trader |
| Efficiency (%) | 85 |
| Input Power Voltage | AC 240V (1 phase) ±10% 50/60 |
| Rated Input Power Capacity(KVA) | 6.4 |
| Output Current Ranges(A) | 50 -200 |
| Rated Output Voltage(V) | 26 |
| Duty Cycle(%) | 60 |
| Weight(KGs) | 25 |
| Power Factor | 0.93 |
| Over all dimension (mm) | 500*263*430 |
| Post Gas (sec) | 1±0.5 |
| Wire Speed m/min | 2.0-10 |
| Welding Coil Dia (mm) | 0.8 |
| Power factor | 0.93 |
| Protection Class of Case | Ip21 |
| Diameter of Arc welding electrode (mm) | 1.6 - 3.15 |
Features
- Power Saving up to 30 - 70 %
- Power Factor (PF) more than 0.9
- Good ARC start and arc force
- Suitable to weld all kind of Electrodes
- Less spatter and good welding bead
- ARC strength can be adjusted due to reactor control technology
- Small, light, portable and cost effective
- Hight duty cycle enables contunies welding.
- Three protection (anti-dust, anti damp proof, antisepsis) user friendly design
| Business Type | Manufacturer, Supplier, Retailer, Trader |
| Input Power Voltage | AC 440V (3 phase) ±15% 50/60 |
| Rated Input Power Capacity(KVA) | 14 |
| Output Current Ranges(A) | 20-400 |
| Rated Output Voltage(V) | 31.5 |
| Duty Cycle(%) | 60 |
| Weight(KGs) | 145 |
| Overall Dimension (mm) | 680 x408 x756 |
| Protection class of case | IP21 |
| Wire Feeder Speed(m/min) | 3 -15 |
| Efficiency (%) | 85 |
| Diameter of Coil (mm) | 0.8 -1.2 |
Features
- Easy control of welding wove, little spark, smooth welding seam, high efficiency
- Adopting electric reactor, energy concentrating, easy arc - starting, stable arc
- Suitable for the solid cored and flux - cored welding wire
- User friendly, high speed in welding, high success rote of arc - starting
- Little spark, deep welding pool, good welding seam, heat • proof and split - proof
- Suitable for mild steel, low carbon steel, alloy steel etc
| Business Type | Manufacturer, Supplier, Retailer, Trader |
| Input Power Voltage | AC 240V (1 phase) ±10% 50/60 |
| Rated Input Power Capacity(KVA) | 4.8 |
| Output Current Ranges(A) | 20 -40 |
| Rated Output Voltage(V) | 96 |
| No Load Voltage(V) | 230 |
| Input Power Freuency(Hz) | 50/60 |
| Duty Cycle(%) | 60 |
| Weight(KGs) | 9 |
| Overall Dimension (mm) | 380 x 170 x 295 |
| Protection class of case | IP23 |
| Gas Flow (M3/min) | 0.17 |
| Cutting Thickness (mm) | 4 |
| Efficiency (%) | 85 |
| Power factor | 0.93 |
Features
\\n- \\n
- Can cut steel, Aluminum, Stainless steel etc \\n
- High cuttingprecision \\n
- Smooth cuttingedge \\n
- Stable output \\n
- Protection on Low/High voltage,over current, over heating and over load, Ensured machine safety, durability and reliability \\n
| Business Type | Manufacturer, Supplier, Retailer, Trader |
| Input Power Voltage | AC 440V (3 phase) ±15% 50/60 |
| Rated Input Power Capacity(KVA) | 55 |
| Output Current Ranges(A) | 1250 |
| Rated Output Voltage(V) | 90 |
| Duty Cycle(%) | 60 |
| Weight(KGs) | 100 |
| Overall Dimension (mm) | 765 x355 x725 |
| Protection Class of Case | IP21 |
| Wire Feeder Speed (m/mm) | 30 -120 |
| Efficiency (%) | 92 |
| Diameter of Wire (mm) | 2 -6 |
| Type | Inverter |
Features
\\n- \\n
- Power Saving up to 30 - 70 % \\n
- High Quality & Spatter less in welding \\n
- Good ARC start and arc force \\n
- Protection against low voltage, high voltage, single phase & surge voltage \\n
- Suitable to weld all kind of Electrodes \\n
- Excellent arc - starting current regulating ability according to welding procedure \\n
- Weld pool is deep, high quality weld bead and shapping. \\n
| Business Type | Manufacturer, Supplier, Retailer, Trader |
| Model | CD-08 |
| Welding Range | DIA 2-8 MM |
| Welding Material | M.s S.s Aluminium |
| Input Power | 250V, 5 AMPS A.C |
| Protective Systems | IP 23 |
| Housing Dimensions | 250W X 350H X 500L |
| Type | Contact |
| Welding Cable | 5 MET |
| Weight | 2.5 (with Cable),22 KG |
